- Accelerator function for fingertip control when pilot sawing
- Exemplary running smoothness when sawing, which ensures best results and low-fatigue working
- When working under extreme conditions its lifetime is up to five times that of conventional tools
- The sole plate can be adjusted without tools (+/– 45° as well as 15 mm forwards/backwards)
- Easy to service thanks to the uncomplicated changing of the cable and carbon brushes
- Sturdy aluminium sole plate with steel reinforcement, also ideal for metalworking
- Sawdust blower enables a clear view, and can be switched off for effective dust extraction
- 4-stage pendulum action for tear-free cuts up to aggressive cuts
Technical data
| Rated power input |
720 W |
| No-load stroke rate |
500 – 2.800 spm |
| Weight |
2,7 kg |
| Cable length |
4 m |
| Stroke height |
26 mm |
| Cutting depth |
|
| Cutting depth in wood |
135 mm |
| Cutting depth in aluminium |
20 mm |
| Cutting depth in non-alloyed steel |
10 mm |
Functions
- Pendulum stroke adjustment
- Dust extraction
- Bosch SDS System
- Electronic
- Constant Electronic
- Saw blade pendulum action
|
|
|
|
|
